S409
S409
Features
- Support Android 11
- octa-core Arm-Cortex A53 2.3GHz CPU
- Built-in calibrator for precise body temperature
- Competitive size and easy to install
- Unibody device for the body temperature and face mask
- Anti-Ultraviolet with Fiber Reinforced Plastic
Specification
System
| CPU | Octa-core Arm-Cortex A53 2.3GHz |
|---|---|
| Operating System | Android 11 |
| ROM (eMMC) | 32GB |
| RAM | 3GB DDR3 |
| Camera module (with thermal) | FF (pixel 4M) / thermal camera 80x60 |
| LED | 3 color LED: Blue: Wi-Fi /4G connecting, Red: No connection, Green: Connected |
| Speaker | 1.5W + MIC |
| Battery | LI-POLYMER,1S1P,4~3.2V, 770mAh |
Mechanical
| Dimension | 154 x 195.8 x 132.3 mm |
|---|---|
| Weight | 1Kg |
| Key | Power key |
| Operating Humidity | 2 x 2 cm |
| Drop | 1.2M |
| Material | Fiber reinforced plastic |
Display
| Display | 5.0” inch HD 1280 × 720 TFT |
|---|---|
| Brightness | 400 +/-20 nits |
Wireless
| WWAN | EU/US bands (EC25AU - mini PCIE ethernetcard) LTE B3,7,8,28 |
|---|---|
| Connectivity | Wi-Fi 802.11 a/b/g/n/ac, BT4.2(BLE), USB2.0 |
| GPS | GPS / A-GPS / Beidou |
Touch Screen
| Type | 10-point Projected Capacitive Multi-Touch |
|---|
I/O
| I/O | USB2.0 (typeC), RJ45, M8, SIM, Micro SD |
|---|
Accessories
| Accessories | Adaptor 9~24V, cable 1.5M |
|---|
