Gladius G1052R

10.4” Intel® Celeron® N2930 Rugged Tablet PC
Gladius G1052R
Gladius G1052R
Gladius G1052R
Gladius G1052R

Gladius G1052R

10.4” Intel® Celeron® N2930 Rugged Tablet PC
Features
BTO
  • 10.4" AFFS+ TFT Active Matrix with Resistive Touch Panel
  • Ultra low power consumption
  • Fully rugged for mobile POS or warehousing application
  • Meeting MIL-STD-810G, IP54, 4 ft. drop resistance
  • High mobility, multiple connectivity (Bluetooth/WLAN/WWAN)
  • Identification devices (barcode scanner, RFID & NFC reader and MSR)
  • Hot-swappable external battery w/ redundant internal battery
  • 23-key keypad with numeric keys and function Keys
  • I.P.A. (Isopropyl) alcohol clearing allowed
Ajoutez à la comparaison
Spécification

System

CPU Intel® Celeron® Processor N2930 quad-core 1.83 GHz
Graphics Controller Intel® HD Graphics
Memory 2GB DDR3L SO-DIMM memory module installed (optional up to 8GB)
BIOS UEFI BIOS
Audio 1 x microphone
1 x 2W speaker
1 x Earphone jack
Storage 1 x 32GB MLC mSATA SSD

Peripherals and Devices

Camera 1 x 5.0 MP rear AF CMOS camera with LED (optional)
WLAN & Bluetooth 1 x WLAN 802.11 a/b/g/n & Bluetooth 4.0 LE, class 2
RFID & NFC 1 x 13.56MHz, ISO 15693/14443A/ 14443B RFID & NFC Reader (distance: 3~5cm; speed: 5 cards/sec)
(optional)
WWAN HSUPA / HSPA+/ LTE (BTO)
Barcode Scanner 1 x 1D/2D Barcode scanner (optional)
MSR 1x Magnetic Stripe Reader (BTO)
Smart Card Reader 1x Smart Card Reader (BTO)
GPS U-BLOX 6 GPS Receiver (BTO)

I/O Interface

USB Port 1 x USB 3.0 Type-A port
SD Card 1 x SD/SDHC/SDXC slot
Docking Port 1 x 35-pin pogo connector for docking connection
Expansion 1 x USB 2.0 Type-A or USB Sensor Hub

Button & Indicator

Function Keys 10 x Numeric keys (0 ~ 9);
1 x Enter key;
1 x 4-way navigation key;
4 x Function keys;
1 x Ctrl key;
1 x Backspace;
1 x Dot (.) key;
1 x Brightness key;
Power Button 1 x Power on/off button
LED Indicators 1 x Battery LED
1 x WLAN/RFID LED
1 x Bluetooth/WWAN LED

Touch Screen

Type Analog Resistive Touch
Light Transparency 80% (typ.)
Controller Interface USB Interface

LCD Display

Size/Type 10.4” XGA TFT color LCD with LED backlight
Max. Resolution 1024 x 768 (XGA) w/ 262,144 colors
Luminance 340 cd/m² (typ.)
Contrast Ratio 600 :1
View Angle (U/D/R/L) 89°/89°/89°/89°
Backlight Type LED

Power Supply

Adapter Input 100 ~ 240VAC (full range)
Adapter Output 19VDC, 3.42A, 65W
Battery Type Li-battery pack
Battery Capacity 1 x 2500mAh 4-cell external battery pack
1 x 1880mAh 3-cell internal battery pack (optional)
Battery Life Up to 8 hours (depends on configuration and use)

OS Support

Windows Embedded 7 / Windows 7 Professional
Windows Embedded Standard 8.0 / Windows Embedded 8.1 Industry Pro / Windows 8.1 Professional
Windows 10 IoT Enterprise 2016 LTSB
Linux: Ubuntu

Ordering Information

G1052R 10.4” Intel® Celeron® N2930 rugged tablet PC with resistive touch, battery pack, WLAN and Bluetooth

Mechanical & Environmental

Operating Temp. -20 ~ 45°C (-4 ~ 113°F)
Storage Temp. -20 ~ 60°C (-4 ~ 140°F)
Discharging Temp. -20 ~ 45°C (-4 ~ 113°F)
Charging Temp. 0 ~ 40°C (32 ~ 104°F)
Operating Humidity 10 ~ 95% @ 45ºC (non-condensing)
Dimensions (W x H x D) 204.9 x 294.1 x 26.2 mm (8.07" x 11.57" x 0.98")
Gross Weight 1.2 kg (2.64 lb) w/o 2-cell internal battery pack
Vibration 20 to 1000 Hz @ 1 grms per MIL-STD 810G (operating)
20 to 1000 Hz @ 3 grms per MIL-STD 810G (nonoperating)
Shock 11 ms @ 20G per MIL-STD 810G for unit only (operating)
11 ms @ 40G per MIL-STD 810G for unit only (nonoperating)
Transit Drop 1.2m (4ft.) per MIL-STD-810G for whole unit
IP Rating IP54
Regulatory CE EN55022 class B
FCC 47 CFR, Part 15 Subpart B
Accessoires

Standard Accessories

  • Power Adapter
    19V/3.42A 65W AC/DC adapter kit
  • Hand Strap
    212mm black elastic hand strap
  • eBAT-1050
    2500mAh 4-cell external battery pack for G105X
  • Stylus
    For touch screen

Optional Accessories

  • Power Adapter
    19V/3.42A 65W AC/DC adapter kit
  • SST-0720
    Shoulder strap, 128 x 3.7cm
  • eBAT-1050
    2500mAh 4-cell external battery pack for G105X
  • iBAT-1040
    1880mAh 3-cell internal battery pack for G105X
  • NST-1050
    Neck Strap, 120 x 4 x 0.6 cm for G105X
  • VSB-100
    VESA-75 to VESA-100 adapter bracket
  • VMB-1050
    VESA mount bracket for G105X
  • DTC-1050
    Desktop cradle for G105X
  • CHR-1050
    Dual-bay external battery charger for G105X

Optional Configuration (CTOS* Kit) (Not Sold Separately)

  • UDG-1050
    USB dongle kit
  • BarC-1052
    1D/2D barcode scanner kit
  • eBAT-1050
    2500mAh 4-cell external battery pack for G105X
  • GRS-1050
    GPS and RS-232 2-in-1 kit
  • SRS-1050
    Smart Card Reader and RS-232 2-in-1 kit
  • MSR-1050
    MSR module kit
  • RFID & NFC-1050
    13.56MHz RFID & NFC kit
  • CAM-1052
    5.0M rear CMOS camera kit
  • LTE-1052
    4G LTE Wireless Kit (BTO)

*CTOS means Configure-to-Order Service.BTO means Build-to-Order.
Note:The GRS, SRS and MSR cannot co-exist on the computer as they occupy the same installation position. Please select any one of them.
