iTC-1150R-EXP/1170R-EXP

Panel PC sans ventilateur, Intel® Elkhart Lake, Module d'alimentation de sauvegarde

iTC-1150R-EXP/1170R-EXP

Panel PC sans ventilateur, Intel® Elkhart Lake, Module d'alimentation de sauvegarde
Features
  • Processeur Intel® Celeron® J6413 (1.5M Cache, jusqu'à 3.00 GHz)
  • 15" 1024 x 768 XGA LCD
  • 17" 1280 x 1024 SXGA LCD
  • Conception sans ventilateur avec face avant Aluminium
  • Face avant complétement plate et lisse avec compatibilité protection contre l'eau IP65
  • Port 2.5GbE LAN et USB 3.2 Gen1 (5Gbps)
  • 6 x COM, 2 x LAN, 4 x USB3.2(5Gbps), 8-bit E/S DI/O
  • Sortie vidéo DisplayPort et DVI-D
  • Accès facilité pour le stockage et le module wifi
  • Alimentation large plage 9~36V DC avec protection d'inversion
  • Supporte les cartes PCIe x 1 1/2 longueur et PCI 32-bit
  • Compatible avec le module de sauvegarde d'alimentation SuperCAP Power Backup module
Ajoutez à la comparaison
Spécification

System

CPU Intel® Celeron® J6413 Quad-Core™ Processor 1.80GHz
Memory 1 x 260 pin DDR4 SO-DIMM socket, supporting 3200MHz SDRAM up to 32GB (4GB DDR4 SO-DIMM pre-installed)
LAN Chipset 1 x Intel® 225LM controller
1 x Intel® i210 / i211AT controller
Watchdog Timer 1~255 levels reset
TPM Support TPM 2.0

LCD Display

Size / Type 15" & 17" TFT LCD Panel
Max. Resolution 15" 1024 x 768, XGA display
17" 1280 x 1024 SXGA LCD display
Max. Colors 15" 16.2M
17" 16.7M
Luminance 15"/17" - 350 cd/m²
Touch Screen Flat 5-wire Analog Resistive
View Angle (U/D/R/L) 88°/88°/88°/88°(iTC-1150R-EXP)
60°/80°/80°/80°(iTC-1170R-EXP)

External I/O

Serial Ports 2 x DB-9 connectors for RS232 / 422 / 485
4 x DB-9 connectors for RS232
USB Ports 4 x Type-A USB 3.2 Gen 1 (5Gbps)
LAN 1 x RJ-45 port for GbE LAN
1 x RJ-45 port for 2.5 GbE LAN
Video Ports 1 x DVI-D connector, supporting Full HD resolution
1 x DisplayPort 1.4 connector, supporting 4K2K resolution
Digital I/O 8 bit Digital I/O

Storage

1st Device 1 x M.2 M-key 2240 / 2280 (SATA III only)
2nd Device 1 x 2.5” SSD / HDD tray
*Not available when SuperCAP module is installed

Audio

Type 1 x Mic-in / 1 x Line out
Speaker 2 x 1.5W speakers (optional)

Button & Indicator

Button Power on & Reset
LED Power-on status / HDD status / RTC battery status

Power System

Power Input DC 9 ~ 36V
DC 12~28V (when SuperCAP module is installed)
Power Consumption Typical 25W (w/o I/O cards)
*when SuperCAP module is installed, min. 60W adapter is required.*(iTC-1150R-EXP)
Typical 40W (w/o I/O cards)
*when SuperCAP module is installed, min. 75W adapter is required.*(iTC-1170R-EXP)
Power Backup time 70 seconds w/ SuperCAP module (800 farads)(iTC-1150R-EXP)
50 seconds w/ SuperCAP module (800 farads)(iTC-1170R-EXP)
Remote Control 1 x 3-pin terminal block for remote control and PWR LED output

Mechanical

Mounting Type Panel mount /
VESA-75 / 100 mount (optional)
Chassis Panel-mounting chassis, aluminum front bezel and steel-metal chassis
Weight (Net) iTC-1150R-EXP: 5.2 kg; iTC-1170R-EXP: 6.3 kg
(w/o I/O cards and SuperCAP module)
Dimensions (W x H x D) 15” - 367 x 299 x 99 mm
17" - 415 x 347 x 100 mm

Environmental

Operating Temp. -10 ~ 55ºC (14 ~ 131ºF)
Storage Temp. -20 ~ 70ºC (-4 ~ 158ºF)
Operating Humidity 10 ~ 95% @ 55°C (non-condensing)
Vibration 5 ~ 500Hz, 1Grms X,Y,Z axis (with SSD)
Shock Operating 10G, 11ms X,Y,Z axis (with SSD)

Qualification

Certification CE, FCC

Expansion

Expansion Bus
(for Wireless connection)
1 x Mini PCIe slot (PCIe x1+ USB2.0, Full size)
w/ 1 x SIM card slot (for Wireless connection)
1 x PCIe x1 slot (for half-length) or
1 x PCI 32-bit slot (both Riser Cards are included
in Standard Accessories)
*when SuperCAP module is installed, PCIex1 and
PCI slot are not avaliable

OS Support

System Windows®10 (64bit)
Windows®11 (64bit)
Accessoires

Optional Accessories

  • PAC-60W6A-FSP-ES
    12V/5A 60W AC/DC power adapter kit
  • PAC-120W6B-FSP-ES
    19V/6.3A 120W AC/DC power adapter kit

    (Note: This item is only for iTC-1170R-EXP with SuperCAP Modue)
  • VMB-1150-EXP/VMB-1170-EXP
    iTC-1150R-EXP/iTC-1170R-EXP VESA-mount bracket kit, w/ 75 x 75 mm & 100 x 100 mm VESA supports
  • 64/128/256GB SSD
    2.5” SSD MLC 64/128/256GB
  • 64GB M.2 SSD
    M.2 M-key 2242/ 2280, 64GB, SATA3.0
  • WiFi-AT4550
    Atheros, QCNFA324 Wi-Fi module w/ 2*30cm internal wiring
  • ANT-D11
    1 x Wi-Fi Dual-band 2.4G / 5G antenna
  • ADK-11X
    iTC-11xx series audio kit
  • SCK-722C
    Assembly kit for SiP-41B/42B
    (Note: SCK-722C can only be installed with VMB-1150-EXP/VMB-1170-EXP Mounting Bracket)
  • SiPB-1690B-HMI
    Accessory Kit for SuperCAP power module
    (Note: Visit the ARBOR website’s Download Center to access the driver and SiP Management Utility files.)
