FPC-7914-HDBT

4K@100M TX HDBaseT™ with PoH Box PC with Intel^® 7th & 6th Generation Core™ i7 / i5 / i3 Processor

특징

Compatible with the Intel^® OpenVINO™ toolkit
Various Video Interfaces (DVI-D+HDMI+ HDBaseT) supported
Optional Wi-Fi or LTE Wireless Connectivity supported
Rugged Design for Shock/Vibration Protection
Memory support up to 32GB
Complies with the HDBaseTTM technology carry USB,4K Display, Power over 100M w/o any signal loss
Support HDMI and USB outputs over a single run of Cat.5e/6/7 cable up to 100M
Support standard PoH from the HDBaseTTM output(PSE) up to 60W
Easier distribution of displays with Daisy-Chainable HDbaseTTM technology

비교하기

사양

CPU	Intel^® 6th & 7th generation Core™ i7/i5/i3 Processor in LGA1151 socket
Memory	2 x 260-pin DDR4 SO-DIMM sockets, supporting 2133 MHz SDRAM up to 32GB
Chipset	Intel^® H110
Graphics	Integrated Intel^® HD Graphics
ATA	2 x Serial ATA ports with 600MB/s HDD transfer rate
LAN Chipset	2 x Intel^® WGI211AT GbE controllers 1 x Intel^® WGI219LM GbE controller w/o iAMT
Watchdog Timer	1~255 levels reset

Serial Port	4 x RS-232 ports via one DB-44 female connector. (COM1 and COM2 are RS-232 / 422 / 485 configurable)
USB Port	6 x USB 2.0 ports (Front side)* 4 x USB 3.0 ports (Rear side)
LAN	3 x RJ-45 ports for GbE
Video Port	1 x HDMI 1 x RJ-45 port for HDBaseT 1 x DVI-D female connector for digital video output * Support 2 independent displays
Expansion Bus	1 x Mini-card socket interconnected with SIM card socket for optional Wi-Fi or LTE module(Full size) 1 x SIM socket/1 x CFast socket (outside accessible)
Selectable Port	1 x DB25 connector for DIO (8 in/8 out) port or LPT port (either one, default is DIO)
Audio	Mic-in / Line-out

*Two of the USB ports are USB 3.0 connector but only USB 2.0 signal at front side.

Operating Temp.	-20 ~ 55°C (-4 ~ 131°F), ambient w/ air flow, for 65W TDP CPU need to configure TDP to 35W via BIOS setting.
Storage Temp.	-40 ~ 85°C (-40 ~ 185°F)
Operating Humidity	10 ~ 95% @ 55°C (non-condensing)
Vibration	3 Grms / 5~500Hz / random operation w/ SSD
Shock	Operating 40G (11ms), Non-operating 60G with SSD

System	Windows 10 IOT (For 6th/7th Gen Intel CPU) Windows 7 / Windows8.1 (For 6th Gen Intel CPU) Linux (Kernel: 4.x)

Type	2 x 2.5” drive bays 1 x CFast socket, can be outside accessible

Certification	CE, FCC Class A

Processor	VS2010TX HDbaseT KVM HDMI USB Extender
Function	Transmit HDMI, USB signal and up to 60W power via 1 x RJ-45 port over up to 100M Cat5e/6/7 cable

Power Input	DC 9 ~ 36V input (w/ 4-pin DC input terminal block,combining remote power on/off switch)
Power Consumption	MAX. 65W (w/o I/O card)

FPC-7914-HDBT	Robust BOX PC w/ HDBaseT Transmitter

액세서리

240GB SSD
Intel^® 2.5” 240GB SATA III SSD kit
MK-4I-4G / 8G / 16G
Industrial-grade DDR4-2133 4GB / 8GB / 16GB SDRAM DIMM kit
WiFi-AT4550
Atheros QCNFA324 Wi-Fi module w/ 2x30cm internal wires
ANT-D11
1 x Wi-Fi Dual-band 2.4G / 5G antenna
Core™ i7-7700T
Intel^® 7th Gen. Core™ i7-7700T processor, L2/8M, 2.9G
Core™ i5-7500T
Intel^® 7th Gen. Core™ i5-7500T processor, L2/6M, 2.7G
Core™ i3-7101TE
Intel^® 7th Gen. Core™ i3-7101TE processor, L2/3M, 3.4G
Core™ i7-7700
Intel^® 7th Gen. Core™ i7-7700 processor, L2/8M, 3.6G, need configure TDP to 35W
Core™ i5-7500
Intel^® 7th Gen. Core™ i5-7500 processor, L2/6M, 3.4G, need configure TDP to 35W

*CTOS means Configure-to-Order Service.
