ARES-1983H-AI Series

Compact Computer w/ Intel^® 14th/13th/12th Gen. Core™ 35W Processors, Featuring MemryX AI Accelerator

New

Features

Fanless / Dual Fan-Sink design for scalable AI performance
Supports 1, 2 or 4 MemryX MX3 M.2 AI modules, started from 24 TFLOPS up to 96 TFLOPS
Dual display: VGA + DisplayPort
2 × internal USB 2.0 ports for HW-License Key & Security Dongle
Up to 8 × USB ports and 3 × LAN ports for versatile connectivity
Group-BF16 activations for higher accuracy than INT8
Thoughtful SDK with Open-Source Model Support

Specification

System
CPU	Intel^® 14th/13th/12th Core™ processors in LGA1700 Socket (Max. 35W)(default: i5-14500T)
AI Accelerator	Supports 1 x MemryX MX3 M.2 AI Accelerator , up to 24 TFLOPS (ARES-1983H-AI-MX) Supports 2 x MemryX MX3 M.2 AI Accelerator , up to 48 TFLOPS (ARES-1983H-AI-2MX) Supports 4 x MemryX MX3 M.2 AI Accelerator , up to 96 TFLOPS (ARES-1983H-AI-4MX)
Memory	1 x 262-pin DDR5 SO-DIMM sockets, supporting 4800/5600MHz SDRAM up to 32GB (Default 8GB: ARES-1983H-AI-MX / ARES-1983H-AI-2MX) (Default 16GB: ARES-1983H-AI-4MX)
Chipset	Intel^® H610E (ARES-1983H-AI-MX / ARES-1983H-AI-2MX) Intel^® Q670E (ARES-1983H-AI-4MX)
Graphics	Integrated Intel^® UHD Graphics 730/770
LAN Chipset	1 x Intel^® i226LM 1 x Intel^® i219LM 1 x Intel^® i210AT
Watchdog Timer	1~255 levels reset
TPM	dTPM 2.0
I/O
Serial Port	1 x RS232 1 x RS232(Default)/422/485
USB Port	2 x USB-A 3.2 Gen2 (10Gbps) (ARES-1983H-AI-MX / ARES-1983H-AI-2MX) 4 x USB-A 3.2 Gen2 (10Gbps) (ARES-1983H-AI-4MX) 2 x USB-A 3.2 Gen1 (5Gbps) 2 x USB-A 2.0 2 x Internal USB-A 2.0
LAN	1 x 2.5GbE ports 2 x GbE ports
Video Port	1 x DisplayPort 1.4 (DP++), up to 4096x2304@60Hz 1 x VGA, up to 1920x1200@60Hz
Expansion Bus	1 x M.2 E-key 2230 slot (PCIe 3.0 x1 + USB2.0 + CNVi) 1 x mPCIe (PCIe 3.0 x1 + USB 2.0, Full size) w/ 1 x nano SIM card slot
Others	4 x Antenna holes
Storage
Type	1 x 2.5” HDD/SSD internal drive bay (default: 256GB) (ARES-1983H-AI-MX) 1 x M.2 M-key 2242/2280 slot (PCIe 4.0 x4 + SATA) (default: 256GB) (ARES-1983H-AI-2MX / ARES-1983H-AI-4MX)

Power Requirement
Power Input	DC 12~24V via 2-pin terminal block
Max. Power Consumption	95W (ARES-1983H-AI-MX) 110W (ARES-1983H-AI-2MX) 140W (ARES-1983H-AI-4MX)
Environmental
Operating Temp.	-5°C~ 50°C (23°F ~ 122°F), ambient w/ air flow -20°C~ 50°C (-4°F ~ 122°F), with industrial grade RAM and SSD, ambient w/ air flow
Storage Temp.	-30°C ~ 70°C (-22°F ~ 158°F)
Operating Humidity	10 ~ 95% @60°C (non-condensing)
Vibration	5~500Hz 3 Grms X,Y,Z axis w/ SSD, according to IEC 68-2-64
Shock & Crash	10G peak acceleration (11 m sec. duration), operation 30G peak acceleration (11 m sec. duration), nonoperation According to IEC 68-2-27
Qualification
Certification	CE, FCC Class A
Mechanical
Construction	Metal + Aluminum
Mounting	Wall-mount (standard), DIN-rail (optional w/ CTOS bracket)
Weight	3.6 kg (ARES-1983H-AI-MX) 3.9 kg (ARES-1983H-AI-2MX) 4.3 kg (ARES-1983H-AI-4MX)
Dimension (W x H x D)	85 x 210 x 164mm (ARES-1983H-AI-MX) 95 x 210 x 164mm (ARES-1983H-AI-2MX / ARES-1983H-AI-4MX)
OS support
System	Windows 10 / Windows 11 / Ubuntu 22.04 / Ubuntu 24.04

Accessories

PAC-120W6B-FSP-ES (ARES-1983H-AI-MX / ARES-1983H-AI-2MX)
19V/6.3A, 120W AC/DC Adapter Kit
PAC-180W6C-FSP-ES (ARES-1983H-AI-4MX)
24V/7.5A, 180W AC/DC Adapter Kit
WiFi-RT1550
Realtek RTL8852CE M.2 2230 Wi-Fi 6E + BT 5.4 Module Kit (w/ 2 x 30cm RF Cable)
ANT-T15
1 x Wi-Fi 6E Tri-band 2.4G/5G/6G Dipole Antenna Kit
ANT-H11
1 x 2dBi HSUPA Antenna Kit
LTE-4450
Quectel EG25-G mPCIe LTE Cat 4 Module Kit (for Global, w/ 1 x 25cm RF Cable)
DRK-002
DIN Rail Mounting Bracket Kit for ARES Series

*CTOS means Configure-to-Order Service.
