Gladius G0975

9.7" Intel® Celeron® N2930 Rugged Tablet PC

Gladius G0975

9.7" Intel® Celeron® N2930 Rugged Tablet PC
Features
  • 9.7” XGA IPS LED display with Projected Capacitive Touch
  • High computing performance from Intel® Quad Core Celeron®
  • Fully rugged for mobile POS or warehousing application
  • Meeting MIL-STD-810G, IP65, 4 ft. drop resistance
  • High mobility, multiple connectivity (Bluetooth/WLAN)
  • Adopting Multi-Touch Screen with Corning® Gorilla® Glass
  • Supporting external battery with battery cover and internal battery
  • Providing four function keys and home key
Add To Compare
Specification

System

CPU Intel® Processor N2930 quad-core 1.83 GHz
Graphics Controller Intel® HD Graphics
Memory 2GB DDR3L SO-DIMM memory module installed (optional up to 8GB)
BIOS UEFI BIOS
Audio 1 x integrated microphone
2 x piezoelectric speaker
1 x 3.5 mm headset combo jack
Storage 1 x 32GB MLC mSATA SSD

Peripherals and Devices

Camera 1 x 5.0 MP rear AF CMOS camera with LED
WLAN & Bluetooth 1 x WLAN 802.11 a/b/g/n & Bluetooth 4.0 LE, class 2
Sensor Accelerometer, Magnetometer, Gyroscope & Light Sensor

I/O Interface

USB Port 1 x USB 3.0 Type-A port
1 x USB 2.0 Micro Type-B port
SD Card 1 x microSD/SDHC/SDXC slot
HDMI 1 x microSD/SDHC/SDXC slot
Docking Port 1 x 8-pin docking connector
Reset 1 x reset button

Button & Indicator

Function Keys 1 x Home key
4 x Function keys
Power Button 1 x Power on/off button
LED Indicators 1 x Power LED
1 x Battery LED
1 x WLAN LED
1 x Bluetooth LED

Touch Screen

Type 10-point Projected Capacitive Touch w/ Corning® Gorilla® Glass
Light Transparency 84.5% (typ.)
Controller Interface USB Interface

LCD Display

Size/Type 9.7” XGA IPS LED display
Max. Resolution 1024x768 (XGA), w/ 262,144 colors
Luminance 350 cd/m² (typ.)
Contrast Ratio 900 : 1
View Angle (U/D/R/L) 89°/89°/89°/89°
Backlight Type LED

Power Supply

Adapter Input 100 ~ 240VAC (Full Range)
Adapter Output 19VDC, 3.42A, 65W
Battery Type Li-battery pack
Battery Capacity 1 x 2270mAh 4-cell external battery pack
1 x 2270mAh 2-cell internal battery pack (optional)
Battery Life Up to 8 hours (depends on configuration and use)

OS Support

Windows Embedded 7 / Windows 7 Professional
Windows Embedded Standard 8.0 / Windows Embedded 8.1 Industry Pro
Windows 10 IoT Enterprise 2015 LTSB
Linux: Ubuntu

Ordering Information

G0975 9.7” Intel® Celeron® N2930 rugged tablet PC with XGA LCD, projected capacitive touch, battery pack,
WLAN, Bluetooth and Rear Camera

Mechanical & Environmental

Operating Temp. -20 ~ 45°C (-4 ~ 113°F)
Storage Temp. -20 ~ 60°C (-4 ~ 140°F)
Charging Temp. 0 ~ 35°C (32 ~ 95°F)
Operating Humidity 10 ~ 95% @ 45ºC (non-condensing)
Dimensions (W x H x D) 260 x 200 x 30.6 mm (10.24” x 7.87” x 1.20”)
Gross Weight 1.0 kg (2.20 lb) w/o 2-cell internal battery pack
Vibration 20 to 1000 Hz @ 1 grms per MIL-STD 810G (operating)
20 to 1000 Hz @ 3 grms per MIL-STD 810G (nonoperating)
Shock 11 ms @ 20G per MIL-STD 810G for unit only (operating)
11 ms @ 40G per MIL-STD 810G for unit only (nonoperating)
Transit Drop 1.2m (4ft.) per MIL-STD-810G for whole unit
IP Rating IP65
Regulatory CE EN55022 class B
FCC 47 CFR, Part 15 Subpart B
Accessories

Standard Accessories

  • Power Adapter
    19V/3.42A 65W AC/DC adapter kit
  • eBAT-1050
    2500mAh 4-cell external battery pack for G105X

Optional Accessories

  • NST-1050
    Neck Strap, 120 x 4 x 0.6 cm for G105X
  • HST-0975
    Hand strap, 160 x 30mm
  • DTC-0975
    Desktop Cradle for G0975
  • VMC-0975
    Vehicle cradle for G0975

Optional Configuration (CTOS* Kit) (Not Sold Separately)

  • iBAT-0975
    2270mAh 2-cell internal battery pack

*CTOS means Configure-to-Order Service.BTO means Build-to-Order.
Note:The GRS, SRS and MSR cannot co-exist on the computer as they occupy the same installation position. Please select any one of them.
